Description
The magnetic stirring tank—also known as a compounding tank, mixing tank, or blending vessel—offers numerous advantages, including energy efficiency, corrosion resistance, high production capacity, ease of cleaning, and a simple structural design. It is primarily utilized to ensure the uniform mixing of ingredients—such as dairy products, sugar, various trace elements, and other compounds—after they have been combined. Consequently, it serves as indispensable equipment for manufacturers in the dairy, beverage, and pharmaceutical industries.
Parameter
Parameter Specifications (1/4)
Items
DG-600
DG-1
DG-1.5
Effective volume (V)
600
1000
1500
Cylinder size(mm)
900×1000
1150×1000
1160×1500
Total height (H)
1950
1950
2450
Sheet thickness
3
3
3
Inlet and outlet caliber
Φ38/Φ51
Φ38/Φ51
Φ38/Φ51
Parameter Specifications (2/4)
Items
DG-2
DG-3
DG-4
Effective volume (V)
2000
3000
4000
Cylinder size(mm)
1400×1220
1600×1500
1620×2000
Total height (H)
2350
2450
2950
Sheet thickness
3
3
3
Inlet and outlet caliber
Φ38/Φ51
Φ38/Φ51
Φ38/Φ51
Parameter Specifications (3/4)
Items
DG-5
DG-6
DG-8
Effective volume (V)
5000
6000
8000
Cylinder size(mm)
1800×2000
1950×2000
2060×2400
Total height (H)
2950
2950
3350
Sheet thickness
3
3
4
Inlet and outlet caliber
Φ38/Φ51
Φ38/Φ51
Φ65/Φ51
Parameter Specifications (4/4)
Items
DG-10
DG-12
DG-15
Effective volume (V)
10000
12000
15000
Cylinder size(mm)
2300×2400
2270×3000
2530×3000
Total height (H)
3350
3950
3950
Sheet thickness
4
4
4
Inlet and outlet caliber
Φ65/Φ51
Φ65/Φ51
Φ65/Φ51
Application
- It can function as a liquid storage tank, mixing tank, buffer tank, water storage tank, or similar vessel.
- It is suitable for applications in various fields, including food processing, dairy production, fruit juice and beverage manufacturing, pharmaceuticals, chemical engineering, and bioengineering.
Configuration
- Quick-opening manhole.
- CIP (Clean-in-Place) spray balls in various configurations.
- Sanitary, insect-proof air vent hood.
- Adjustable triangular support legs.
- Removable inlet pipe assembly.
- Thermometer (configured according to customer requirements).
- Access ladder (configured according to customer requirements).
- Paddle-type agitator.
- Liquid level gauge and level control system (configured according to customer requirements).
- Anti-vortex baffle plates.
