Product Brief
This DG series single-layer storage tank is mainly applied for temporary storage and mixing of various liquid materials in dairy, juice beverage, beer brewing, chemical and bioengineering industries. It is available in both non-agitating and agitating configurations with multiple impeller types to match different process demands. Fabricated with food-grade stainless steel and hygienic structure, it features reliable performance, easy operation and flexible configuration, serving as universal storage and mixing equipment for liquid processing production lines.
Technical Description
- Material: Fully made of high-quality SUS304-2B or SUS316L stainless steel, cylinder wall thickness: 3–4mm.
- Structure Features: Single-layer cylindrical tank body, supported by triangular or cylindrical support legs.
- Agitation Options: Available in non-agitating or agitating version. Agitation types include paddle type, anchor type, propeller type and frame type.
Standard Configuration
- Closed manhole
- Fly and insect-proof breathable cap
- PT100 digital thermometer
- CIP cleaning ball
- Material inlet and outlet ports
- Lever valve
- Adjustable triangular support legs
- Sampling valve
Technical Parameters
Model Specifications (1/4)
Items
DG-600
DG-1
DG-1.5
Effective Volume (L)
600
1000
1500
Cylinder Size (mm)
900×1000
1150×1000
1160×1500
Total Height (mm)
1950
1950
2450
Plate Thickness (mm)
3
3
3
Inlet/Outlet Diameter (mm)
φ38 / φ51
φ38 / φ51
φ38 / φ51
Model Specifications (2/4)
Items
DG-2
DG-3
DG-4
Effective Volume (L)
2000
3000
4000
Cylinder Size (mm)
1400×1220
1600×1500
1620×2000
Total Height (mm)
2350
2450
2950
Plate Thickness (mm)
3
3
3
Inlet/Outlet Diameter (mm)
φ38 / φ51
φ38 / φ51
φ38 / φ51
Model Specifications (3/4)
Items
DG-5
DG-6
DG-8
Effective Volume (L)
5000
6000
8000
Cylinder Size (mm)
1800×2000
1950×2000
2060×2400
Total Height (mm)
2950
2950
3350
Plate Thickness (mm)
3
3
4
Inlet/Outlet Diameter (mm)
φ38 / φ51
φ38 / φ51
φ65 / φ51
Model Specifications (4/4)
Items
DG-10
DG-12
DG-15
Effective Volume (L)
10000
12000
15000
Cylinder Size (mm)
2300×2400
2270×3000
2530×3000
Total Height (mm)
3350
3950
3950
Plate Thickness (mm)
4
4
4
Inlet/Outlet Diameter (mm)
φ65 / φ51
φ65 / φ51
φ65 / φ51
Data is for reference only. Specifications are subject to change without prior notice due to continuous R&D improvement.
Application Fields
- Dairy industry: Temporary storage and mixing of fresh milk, liquid dairy products and milk-based ingredients
- Beverage industry: Storage and blending of juice, tea beverage, syrup and other liquid raw materials
- Brewing industry: Temporary storage and process transfer of beer, fruit wine and fermentation broth
- Food processing industry: Storage and mixing of liquid condiments, plant extracts and food additives
- Chemical & bioengineering: Storage and mixing of liquid raw materials, intermediate products and process solutions in chemical, pharmaceutical and bioengineering fields
